AZ100 Pier Adaptor

This adaptor bolts directly to the base of the AZ100.
The AZ100 will then fit EQ5 or HEQ5 tripod heads using a M10 bolt. Or photo tripods with 3/8" stud.
The tripod central bolt must protrude a minimum 10mm above the tripod top face for sufficient thread engagement.
NOTE: Some tripods may require the central bolt exchanging for a longer type.

Alternatively this adaptor allows fitting the AZ100 directly to a pier surface with out the need to access from below.
The pier top will require 4 x M8 tapped holes on 90.0mm circle.
CNC machined and black anodised finished and supplied with stainless steel hardware.
